ENGINE
Engine Type
4-Stroke Twin Cylinder
Displacement
760cc High Output (H.O.)
Fuel System
Electronic Fuel Injection
DRIVETRAIN
Transmission/Final Drive
Automatic PVT P/R/N/L/H; Shaft
Drive System
On-Demand True AWD/2WD
SUSPENSION
Front Suspension
Fox Internal Floating Piston 12" (30.5 cm) Travel
Rear Suspension
Dual A-Arm Fox IFP, Rolled with Anti-Sway Bar 12" (30.5 cm) Travel
BRAKES
Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front Calipers
Parking Brake
Park in Transmission
TIRES / WHEELS
Front Tires
27 x 9-12; Maxxis Bighorn
Rear Tires
27 x 12-12; Maxxis Bighorn
Wheels
Cast Aluminum
DIMENSIONS / CAPACITIES
Wheelbase
107.4" (261.6 cm)
Dry Weight
1,282 lbs (582 kg)
Overall Vehicle Size (L x W x H)
130 x 60.5 x 75 in (330.2 x 153.7 x 190.5 cm)
Ground Clearance
11.6" (29.5 cm)
Fuel Capacity
7.25 gal (27.4 L)
Bed Box Dimensions (L x W x H)
22 x 42 x 6.5 in (56 x 107 x 16.5 cm)
Front/Rear Rack or Box Capacity
N.A./300 lb (136.1 kg)
Payload Capacity
900 lb (408.2 kg)
Hitch Towing Rating
1,500 lb (680.4 kg)
Hitch/Type
Standard/1.25" Receiver
Cooling System
Liquid
FEATURES
Cargo System
Lock & Ride
Lighting
Halogen, 55W low/ 60W high
Electronic Power Steering
Equipped
Instrumentation
Digital Gauge, Speedometer, Odometer, Tachometer, Tripmeter, Hour Meter, Clock, Gear Indicator, Fuel Gauge, Hi-Temp/Low-Batt Lights, DC Outlets (2)
